Robot Component

3 Robot Component — 30 mm, 50 mm · 1 mm: 50 mm/s; 2 mm: 100 mm/s; 4 mm: 200 mm/s; 6 mm: 300 mm/s

Exact SKU: ES-EC-S01-M001

Confirm stroke, load, speed, mounting, drive interface, duty cycle and installation envelope before final selection.

Stroke

30 mm, 50 mm

Maximum speed

1 mm: 50 mm/s; 2 mm: 100 mm/s; 4 mm: 200 mm/s; 6 mm: 300 mm/s

Mass

Non-brake — 30 mm stroke: 0.47 kg; 50 mm stroke: 0.55 kg; brake — 30 mm stroke: 0.54 kg; 50 mm stroke: 0.62 kg

Frame size

3

Body variant

Standard body

Lead screw pitch

1 mm; 2 mm; 4 mm; 6 mm

Rated thrust

1 mm: 200 N; 2 mm: 100 N; 4 mm: 50 N; 6 mm: 30 N

Minimum thrust

1 mm: 78 N; 2 mm: 41 N; 4 mm: 21 N; 6 mm: 12 N
