Medium-Power Servo Drive Series — ES-SD-C21-S001

Medium-power servo drive records organized for supply, motor current, overload, feedback and fieldbus engineering review.

Capture supply architecture, continuous and overload current, feedback, braking, fieldbus and safety context before engineering review.

Medium-Power Servo Drive 6 public SKU records RFQ specification review
Request a Quote

Save a recorded candidate and its engineering context to the RFQ basket. CAD / STEP files remain subject to controlled review.

Common Specs

Shared platform specifications

Platform invariants

Product form
Medium-Power Servo Drive
Selection basis
RFQ target specification review
Document access
Controlled review; no automatic CAD release

Drive Architecture & Motor Pairing

Define the medium-power servo drive operating envelope

Capture supply architecture, continuous and overload current, feedback, braking, fieldbus and safety context before engineering review.

No catalog values selected.
Step 1 of 2

Supply voltage

Choose one recorded catalog option.

Technical Verification Technical SKU matrix The table shows approved model-level engineering evidence independently of automatic selection. Missing values remain explicit and prevent unsupported compatibility claims. 6 candidate records
Model Communication Protocol Supply Voltage Logic Supply Voltage Continuous Output Current Peak Output Current Feedback Architecture Braking Resistor Cooling Method Operating Temperature Action
ES-SD-C21-S001-V001 RS232 1-phase 220 VAC -20%/+15%, 47–63 Hz 18VDC～30VDC 1A 2 A 7 A 2500 PPR incremental differential 5 V encoder External braking resistor required according to duty cycle, particularly for rapid start/stop operation Natural convection cooling 0–40 °C
Request Quote
ES-SD-C21-S001-V002 RS232 1-phase 220 VAC -20%/+15%, 47–63 Hz 18VDC～30VDC 1A 4 A 15 A 2500 PPR incremental differential 5 V encoder External braking resistor required according to duty cycle, particularly for rapid start/stop operation Natural convection cooling 0–40 °C
Request Quote
ES-SD-C21-S001-V003 RS232 1-phase 220 VAC -20%/+15%, 47–63 Hz 18VDC～30VDC 1A 4.6 A 15 A 2500 PPR incremental differential 5 V encoder External braking resistor required according to duty cycle, particularly for rapid start/stop operation Forced-air cooling 0–40 °C
Request Quote
ES-SD-C21-S001-V004 RS232 1-/3-phase 220 VAC -20%/+15%, 47–63 Hz 18VDC～30VDC 1A 11 A 27.5 A 2500 PPR incremental differential 5 V encoder External braking resistor required according to duty cycle, particularly for rapid start/stop operation Forced-air cooling 0–40 °C
Request Quote
ES-SD-C21-S001-V005 RS232 3-phase 380 VAC -20%/+15%, 47–63 Hz 18VDC～30VDC 1A 5.5 A 15 A 2500 PPR incremental differential 5 V encoder External braking resistor required according to duty cycle, particularly for rapid start/stop operation Forced-air cooling 0–40 °C
Request Quote
ES-SD-C21-S001-V006 RS232 3-phase 380 VAC -20%/+15%, 47–63 Hz 18VDC～30VDC 1A 7 A 25 A 2500 PPR incremental differential 5 V encoder External braking resistor required according to duty cycle, particularly for rapid start/stop operation Forced-air cooling 0–40 °C
Request Quote

Product Visualization

Product imagery and CAD-style placeholders are organized for engineering review without exposing private source files.

Product image

Product image

2D Dimension Data

Representative structured preview

2D dimension drawing recorded · controlled access. This series view shows a representative extracted drawing. Open an exact SKU page for full 2D structure, dimension tables and notes.

Request Full Drawing Package
Power Connector Pinout extracted from dimension drawing for Medium-Power Servo Drive Series — ES-SD-C21-S001
Controlled structure diagram preview for envelope review

Structure previews

3 recorded

Dimension tables

0 recorded

Notes / text blocks

0 recorded

Engineering Files

Controlled documentation review

Model-level document relationships remain under evidence review. Preserve the required document types with the RFQ; engineering must confirm each record-to-file relationship before controlled access.

Documentation scope pending record mapping

Engineering confirms the model and file relationship before any controlled record is released.

Controlled 3D CAD requests

Mechanical envelopes can differ by power, stack, brake or winding configuration.

Submit the structured requirements before controlled CAD / STEP review. All files remain pending engineering review until the record-to-file relationship is confirmed.

Application Fit / RFQ

Where this platform fits

Use the SKU matrix to narrow the recorded public model before requesting controlled documentation or adding the item to the RFQ list.

Submit series RFQ Request controlled CAD / STEP review

OEM INTEGRATION RESPONSIBILITY

This product is a component or configurable module intended for integration into an OEM, commercial, industrial or research system.

The customer is responsible for final product selection, system-level risk assessment, safety functions, mechanical and electrical integration, validation, certification and regulatory compliance.

Published ratings apply only under the stated conditions. Confirm the operating point, interfaces, control compatibility, thermal conditions, duty cycle and required documentation before final selection.

This product is not approved for a safety-critical or restricted application unless expressly authorized in writing.

ELECTRONIC SYSTEM INTEGRATION

Confirm power supply, grounding, overcurrent protection, EMC, communications, firmware compatibility, fault behavior, cybersecurity requirements and interaction with the system safety architecture.

Standard control or diagnostic functionality is not represented as fail-safe or safety-rated unless expressly documented.
