AC Servo Motors
Browse published AC servo motor configurations for automation axes, robot joints and robot peripherals. Start with frame size and rated power, then narrow the exact SKUs by speed, torque, voltage context, holding brake and feedback. Recorded values support selection review but do not replace application verification.
17
Product platforms
203
Published configurations
Engineering Documentation
- 2D drawings
- Recorded for 203 configurations · Controlled release by request
- 3D CAD
- Recorded for 203 configurations · Controlled release by request
Selection problem
Selecting the right AC servo motor configuration
Start with the mechanical envelope and target operating point. Use the available SKU-level values to narrow frame size, power, speed and torque, then confirm voltage context, holding brake, feedback and required engineering files for the exact configuration.
Frame Size
Use the installation envelope, flange dimensions and joint packaging limits to narrow the available exact SKUs.
Rated Power
Compare continuous operating demand rather than selecting only from the largest recorded output value.
Rated Speed
Use the required axis speed together with the load profile and transmission ratio.
Continuous and Peak Torque
Use torque values only when the source data is verified; do not infer torque from model codes or power alone.
Voltage Context
Confirm whether a recorded value represents motor rated voltage, drive supply class, AC line input or DC bus context.
Brake Requirement
Review holding and release requirements for vertical axes or safety-related stopping conditions.
Feedback Type
Confirm encoder or feedback compatibility using model-level documentation.
Engineering Files
Confirm the required 2D drawing and controlled 3D CAD records against the selected Exact SKU.
Category selection guide
Category selection guide
Compare the product platforms, key selection parameters and SKU confirmation steps for this category in one document.
Category selection guide
AC Servo Motors Category Selection Guide
Compare product platforms, key selection parameters and application requirements to narrow your options.
Documentation to confirm
Documentation to confirm
Availability is confirmed during engineering review.
- PDF datasheet
- Dimensional drawing
- STEP / STP
- Torque-speed curve
- Connector definition
- Brake option table
- Feedback / encoder option table
- Drive pairing documentation
Prepare for RFQ
Prepare for RFQ
Submit the known frame size, rated power, target speed, load context, voltage definition and application information.
- Target frame size
- Rated power
- Rated speed
- Continuous load torque
- Peak load condition
- Duty cycle
- Voltage context
- Brake requirement
- Feedback requirement
- Estimated quantity
- Target timeline
- Required engineering files
